Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm
|
|
Max. Aperture
|
F2.0
|
|
Field of View
|
2.8 mm:
Horizontal: 100°; Vertical: 53°; Diagonal: 120°
3.6 mm:
Horizontal: 86°; Vertical: 43°; Diagonal: 102°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 0.6 m (1.97 ft)
3.6 mm: 1.0 m (3.28 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8mm
|
46.9 m
(153.87 ft)
|
18.8 m
(61.68 ft)
|
9.4 m
(30.84 ft)
|
4.7 m
(15.42 ft)
|
|
3.6mm
|
58.8 m (192.91 ft)
|
23.5 m
(77.10 ft)
|
11.8 m
(38.71 ft)
|
5.9 m
(19.36 ft)
|
|
Video
|
|
Video Compression
|
H.264B; H.264; H.264H; H.265
|
|
Smart Codec
|
Smart H.265+; Smart H.264+
|
|
Video Frame Rate
|
Mainstream:
1920 × 1080 (1–25/30 fps)
Sub stream:
640 × 480@ (1–25 fps)
640 × 480@ (1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Stream Capability
|
2 streams
|
|
Resolution
|
1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H264: 24 kbps–4096 kbps
H265: 9 kbps–4096 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
WDR
|
DWDR
|
|
White Balance
|
Auto; natural; streetlamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
1024 kbps (1080p)
|
|
Smart Illumination
|
Yes
|
|
Image Rotation
|
0°/180°
|
|
Mirror
|
Yes
|
|
Audio
|
|
Built-in MIC
|
Yes
|
|
Built-in Speaker
|
Yes
|
|
Audio Compression
|
G.711a; G.711Mu
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; intensity change
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
Wi-Fi
|
IEEE802.11b/g/n 2.4–2.4835 GHz; 2.4 G
|
|
Wireless Range
|
Up to 150 m (The performance varies based on
actual environment)
|
|
SDK and API
|
Yes
|
|
Cyber Security
|
Video encryption; configuration encryption; Digest.
WSSE; account lockout; security logs; generation and
importing of X.509 certification; HTTPS; trusted boot.
trusted execution; trusted upgrade
|
|
Network Protocol
|
IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP
|
|
Interoperability
|
ONVIF (Profile S/Profile T); CGI; P2P
|
|
User/Host
|
6 (Total bandwidth: 36 M)
|
|
Storage
|
Micro SD card (support max. 256 GB)
|
|
Browser
|
IE
Chrome
Firefox
|
|
Management Software
|
Smart PSS; DSS; DMSS
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1.
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU.
CE-RED: Radio Equipment Directive 2014/53/EU.
FCC:47 CFR FCC Part 15, Subpart B.
FCC ID: FCC PART 15C
|
|
Power
|
|
Power Supply
|
12 VDC
|
|
Power Consumption
|
Basic: 2.2 W (12 VDC)
Max. (H.265+IR intensity):6.21 W (12 VDC)
|
|
Environment
|
|
Operating Temperature
|
–30 °C to +50 °C (–22 °F to +122 °F)
|
|
Operating Humidity
|
≤ 95%
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing
|
Front cover: Plastic
Rear: Plastic
Bracket: Metal
|
|
Product Dimensions
|
180 mm × 83.3 mm × 114.8 mm (7.09" × 3.28" × 4.52")
|
|
Net Weight
|
350.1 g (0.77 lb)
|
|
Gross Weight
|
588.1 g (1.30 lb)
|
