Camera
|
|
Image Sensor
|
1/3" CMOS
|
|
Max. Resolution
|
2880 (H) × 1620 (V)
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Illumination Distance
|
Up to 10 m (32.81 ft) (IR)
|
|
Illuminator On/Off Control
|
Auto
|
|
Illuminator Number
|
1 (IR LED)
|
|
Angle Adjustment
|
Tilt: -5° to 80°
Pan: 0° to 350°
|
|
Lens
|
|
Max. Aperture
|
F2.0
|
|
Field of View
|
H: 74°; V: 41°; D: 88°
|
|
Intelligence
|
|
Human Detection
|
Yes
|
|
Video
|
|
Video Compression
|
H.265
|
|
Video Frame Rate
|
Mainstream: 2880 × 1620@ (1-25/30 fps)
sub stream: 640 × 360@ (1-25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Resolution
|
5M (2880 × 1620); nHD (640 × 360)
|
|
Video Bit Rate
|
H.265: 40 kbps–4096 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
WDR
|
DWDR
|
|
Motion Detection
|
Yes
|
|
Image Rotation
|
0°/180°
|
|
Audio
|
|
Built-in MIC
|
Yes
|
|
Built-in Speaker
|
Yes
|
|
Audio Compression
|
G.711a
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
Wi-Fi
|
IEEE 802.11b/g/n/ax 2.412-2.472 GHz,2.4G
|
|
Storage
|
Micro SD card (up to 256 GB)
|
|
Management Software
|
DMSS
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
Certifications
|
CE
|
|
Power
|
|
Power Supply
|
5 VDC, 1 A
|
|
Power Consumption
|
Basic: 1.9 W.
Max.: 3.8 W (live + IR + PT rotation)
|
|
Environment
|
|
Operating Temperature
|
–10 °C to +45 °C (+14 °F to + 113 °F)
|
|
Operating Humidity
|
≤95%
|
|
Structure
|
|
Casing Material
|
Plastic
|
|
Product Dimensions
|
φ84 mm × 123.8 mm (φ3.31" × 4.87")
|
|
Net Weight
|
206.5 g (0.46 lb)
|
