Pre-order: will take 2-3 days for process.    Technical Specifications: Hardware External Port 1×10/100/1000 Mbps (WAN)3×10/100/1000 Mbps (LAN) Reset Button 1 WPS Button 1 Power Consumption <18W Memory 256 MB Indicator Light PWR Wireless Standard 2.4 GHz: 802.11 b/g/n/ax5 GHz: 802.11 a/b/g/n/ac/ax Performance Operating Frequency 2.412GHz – 2.472 GHz5.170GHz – 5.330 GHz5.735GHz – 5.835 GHz Wireless Transmission Rate 2.4 GHz: 574 Mbps5 GHz: 2402 Mbps Channel Width 20/40/80/160 MHz Max. Output Power CE EIRP: ≤20 dBm@2400-2483.5 MHz ≤23 dBm@5150-5250 MHz ≤23 dBm@5250-5350 MHz ≤27 dBm@5470-5725 MHz ≤14 dBm@5725-5850 MHz FCC output power: ≤27 dBm@2400-2483.5 MHz ≤24 dBm@5150-5250 MHz ≤24 dBm@5250-5350 MHz ≤24 dBm@5470-5725 MHz ≤30 dBm@5725-5850 MHz Antenna Gain 2.4 GHz: 5 dBi (±0.5)5 GHz: 5 dBi (±0.5) Receiver Sensitivity 5 GHz11ac VHT80_MCS0: -89 dbm11ac VHT80_MCS9: -62 dbm11ax VHT160_MCS0: -88 dbm11ax VHT160_MCS11: -55 dbm11ax HE80_MCS0: -89 dbm11ax HE80_MCS11: -59 dbm11ax HE160_MCS0: -85 dbm11ax HE160_MCS11: -55 dbm2.4 GHz11n HT20_MCS0: -95 dbm11n HT20_MCS7: -75 dbm11n HT40_MCS0: -92 dbm11n HT40_MCS7: -72 dbm11ax HE20_MCS0: -95 dbm11ax HE20_MCS11: -65 dbm11ax HE40_MCS0: -92 dbm11ax HE40_MCS11: -62 dbm Channel 2.4 GHz; 1-135 GHz: 36/40/44/48/149/151/153/157/161/165 Connected Wireless Terminals Up to 128 Feature Operating Mode Router; repeater Encryption Mode WPA-PSK; WPA2-PSK; WPA-PSK/WPA2-PSK; WPA3-PSK; WPA2-PSK/WPA3-PSK Firmware Update Web updateWiLynk App update OFDMA Yes MU-MIMO 2x2 DHCP Yes NAT Mapping based on port QoS Yes DDNS Yes Parental Controls Yes Equipment Management Web/WiLynk App Software Firewall; end device management General Power Supply 12 VDC,1.5 A Operating Temperature 0 °C to 40 °C (32 °F to 104 °F) Storage Temperature –40 °C to +70 °C (–40 °F to 158 °F) Operating Humidity 10%–95% (RH), non-condensing Gross Weight 0.86 kg (1.90 lb) Net Weight 0.36 kg (0.79 lb) Packaging Dimensions 470 mm × 295 mm × 60 mm (18.50" × 11.61" × 2.36")(L × W × H) Product Dimensions 262.2 mm × 150.1 mm × 184.5 mm (10.32" × 5.91" × 7.26")(L × W × H) Statics Protection Air discharge: 8 kV; Contact discharge: 6 kV Lighting Protection Common mode: 2 kV; Differential mode: 0.5 kV Installation Desktop mount; wall mount

Read more less

Pre-order: will take 2-3 days for process.  Specifications:  Camera Image Sensor 1/3" CMOS Max. Resolution 2880 (H) × 1620 (V) Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Illumination Distance Up to 30 m (98.43 ft) (IR);Up to 30 m (98.43 ft) (Warm Light) Illuminator On/Off Control Auto Illuminator Number 2 (IR LED); 2 (Warm light) Angle Adjustment Pan: 0°–355°;Tilt: 0°–90° Lens Max. Aperture F1.6 Field of View H: 78°; V: 40°; D: 93° Intelligence Vehicle Detection Yes Human Detection Yes Video Video Compression H.265 Video Frame Rate Mainstream: 2880 × 1620@ (1-25/30 fps)sub stream: 640 × 360@ (1-25/30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Resolution 5M (2880 × 1620); nHD (640 × 360) Video Bit Rate H.265: 80 kbps–4096 kbps Day/Night Auto(ICR)/Color/B/W WDR DWDR Motion Detection Yes Smart Illumination Yes Image Rotation 0°/180° Audio Built-in MIC Yes, built-in Mic Built-in Speaker Yes, built-in speaker Audio Compression G.711a Network Network Port RJ-45 (10/100 Base-T) Wi-Fi IEEE 802.11b/g/n/ax 2.412-2.472 GHz, 2.4 G Storage Micro SD card (up to 256 GB) Management Software DMSS Mobile Client iOS; Android Certification Certifications CE Power Power Supply 12 VDC, 1 A Power Consumption Basic: 1.68 WMax.: 4.56 W (H.265+warm light on) Environment Operating Temperature –20 °C to +50 °C (–4 °F to +122 °F) Operating Humidity ≤95% Structure Casing Material Plastic Product Dimensions 116 mm × 138 mm × 139 mm (4.57" × 5.43" × 5.47") (L × W × H) Net Weight 425 g (0.94 lb)

Read more less

Pre-order: will take 2-3 days for process.  Specifications:  Camera Image Sensor 1/2.7" CMOS Max. Resolution 2304 (H) × 1296 (V) Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Illumination Distance Up to 30 m (98.43 ft) (IR);Up to 30 m (98.43 ft) (Warm Light) Illuminator On/Off Control Auto Illuminator Number 2 (IR LED); 2 (Warm light) Angle Adjustment Pan: 0°–355°;Tilt: 0°–90° Lens Max. Aperture F1.6 Field of View H: 87°; V: 44°; D: 105° Intelligence Vehicle Detection Yes Human Detection Yes Video Video Compression H.265 Video Frame Rate Mainstream: 2304 × 1296@ (1-25/30 fps)sub stream: 640 × 360@ (1-25/30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Resolution 3M (2304 × 1296); nHD (640 × 360) Video Bit Rate H.265: 80 kbps–4096 kbps Day/Night Auto (ICR)/Color/B/W WDR DWDR Motion Detection Yes Smart Illumination Yes Image Rotation 0°/180° Audio Built-in MIC Yes, built-in Mic Built-in Speaker Yes, built-in speaker Audio Compression G.711a Network Network Port RJ-45 (10/100 Base-T) Wi-Fi IEEE 802.11b/g/n/ax 2.412-2.472 GHz, 2.4 G Storage Micro SD card (up to 256 GB) Management Software DMSS Mobile Client iOS; Android Certification Certifications CE Power Power Supply 12 VDC Power Consumption Basic: 1.56 W;Max.: 4.56 W (H.265+warm light on) Environment Operating Temperature –20 °C to +50 °C (–4 °F to +122 °F) Operating Humidity ≤95% Structure Casing Material Plastic Product Dimensions 116 mm × 138 mm × 139 mm (4.57" × 5.43" × 5.47") (L × W × H) Net Weight 425 g (0.94 lb)

Read more less

Pre-order: will take 2-3 days for process.    Specifications:  Camera Image Sensor 1/2.7" CMOS Max. Resolution 2880 (H) × 1620 (V) Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Illumination Distance Up to 10 m (32.81 ft) (IR) Illuminator On/Off Control Auto Illuminator Number 1 (IR LED) Angle Adjustment Pan: 0° to 360°;Tilt: -10° to 70° Lens Max. Aperture F2.0 Field of View H: 90°; V: 49°; D: 106° Intelligence Human Detection Yes Video Video Compression H.265 Video Frame Rate Mainstream: 2880 × 1620@ (1-25/30 fps)sub stream: 640 × 360@ (1-25/30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Resolution 5M (2880 × 1620); nHD (640 × 360) Video Bit Rate H.265: 80 kbps–4096 kbps Day/Night Auto (ICR)/Color/B/W WDR DWDR Motion Detection Yes Image Rotation 0°/180° Audio Built-in MIC Yes, built-in Mic Built-in Speaker Yes, built-in speaker Audio Compression G.711a Network Wi-Fi IEEE 802.11b/g/n/ax 2.412-2.472 GHz,2.4G Storage Micro SD card (up to 256 GB) Management Software DMSS Mobile Client iOS; Android Certification Certifications CE Power Power Supply 5 VDC, 1 A Power Consumption Basic: 1.65 W;Max.: 2.75 W (H.265+ IR intensity) Environment Operating Temperature –10 °C to +45 °C (14 °F to +113 °F) Operating Humidity ≤95% Structure Casing Material Plastic Product Dimensions Φ68 mm × 31.9 mm × 119.2 mm (2.68" × 1.26" × 4.69") Net Weight 95 g (0.21 lb)

Read more less

Pre-order: will take 2-3 days for process.    Specifications:  Camera Image Sensor 1/3.2" CMOS Max. Resolution 2304 (H) × 1296 (V) Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Illumination Distance Up to 10 m (32.81 ft) (IR) Illuminator On/Off Control Auto Illuminator Number 1 (IR LED) Angle Adjustment Pan: 0° to 360°.Tilt: -10° to 70° Lens Max. Aperture F2.0 Field of View H: 99°; V: 55°; D: 117° Intelligence Human Detection Yes Video Video Compression H.265 Video Frame Rate Mainstream: 2304 × 1296@ (1-25/30 fps)sub stream: 640 × 360@ (1-25/30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Resolution 3M (2304 × 1296); nHD (640 × 360) Video Bit Rate H.265: 80 kbps–4096 kbps Day/Night Auto (ICR)/Color/B/W WDR DWDR Motion Detection Yes Image Rotation 0°/180° Audio Built-in MIC Yes, built-in Mic Built-in Speaker Yes, built-in speaker Audio Compression G.711a Network Wi-Fi IEEE 802.11b/g/n/ax 2.412-2.472 GHz,2.4G Storage Micro SD card (up to 256 GB) Management Software DMSS Mobile Client iOS; Android Certification Certifications CE Power Power Supply 5 VDC, 1 A Power Consumption Basic: 1.49 W;Max.: 2.48 W (H.265+ IR intensity) Environment Operating Temperature –10 °C to +45 °C (14 °F to +113 °F) Operating Humidity ≤95% Structure Casing Material Plastic Product Dimensions Φ68 mm × 31.9 mm × 119.2 mm (2.68" × 1.26" × 4.69") Net Weight 95 g (0.21 lb)

Read more less

Pre-order: will take 2-3 days for process.    Specifications:  Camera Image Sensor 1/3" CMOS Max. Resolution 2880 (H) × 1620 (V) Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Illumination Distance Up to 10 m (32.81 ft) (IR) Illuminator On/Off Control Auto Illuminator Number 1 (IR LED) Angle Adjustment Tilt: -5° to 80°Pan: 0° to 350° Lens Max. Aperture F2.0 Field of View H: 74°; V: 41°; D: 88° Intelligence Human Detection Yes Video Video Compression H.265 Video Frame Rate Mainstream: 2880 × 1620@ (1-25/30 fps)sub stream: 640 × 360@ (1-25/30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Resolution 5M (2880 × 1620); nHD (640 × 360) Video Bit Rate H.265: 40 kbps–4096 kbps Day/Night Auto (ICR)/Color/B/W WDR DWDR Motion Detection Yes Image Rotation 0°/180° Audio Built-in MIC Yes Built-in Speaker Yes Audio Compression G.711a Network Network Port RJ-45 (10/100 Base-T) Wi-Fi IEEE 802.11b/g/n/ax 2.412-2.472 GHz,2.4G Storage Micro SD card (up to 256 GB) Management Software DMSS Mobile Client iOS; Android Certification Certifications CE Power Power Supply 5 VDC, 1 A Power Consumption Basic: 1.9 W.Max.: 3.8 W (live + IR + PT rotation) Environment Operating Temperature –10 °C to +45 °C (+14 °F to + 113 °F) Operating Humidity ≤95% Structure Casing Material Plastic Product Dimensions φ84 mm × 123.8 mm (φ3.31" × 4.87") Net Weight 206.5 g (0.46 lb)

Read more less

Pre-order: will take 2-3 days for process.    Specifications:  Camera 3MP Indoor Fixed-focal Wi-Fi Pan & Tilt Network Camera 1/3.2" CMOS Max. Resolution 2304 (H) × 1296 (V) Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Illumination Distance Up to 10 m (32.81 ft) (IR) Illuminator On/Off Control Auto Illuminator Number 1 (IR LED) Angle Adjustment Pan: 0° to 350° Tilt: -5° to 80° Lens Max. Aperture F2.0 Field of View H: 79°; V: 43°; D: 94° Intelligence Human Detection Yes Video Video Compression H.265 Video Frame Rate Mainstream: 2304 × 1296@ (1-25/30 fps)sub stream: 640 × 360@ (1-25/30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Resolution 3M (2304 × 1296); nHD (640 × 360) Video Bit Rate H.265: 40 kbps–4096 kbps Day/Night Auto (ICR)/Color/B/W WDR DWDR Motion Detection Yes Image Rotation 0°/180° Audio Built-in MIC Yes Built-in Speaker Yes Audio Compression G.711a Network Network Port RJ-45 (10/100 Base-T) Wi-Fi IEEE 802.11b/g/n/ax 2.412-2.472 GHz,2.4G Storage Micro SD card (up to 256 GB) Management Software DMSS Mobile Client iOS; Android Certification Certifications CE Power Power Supply 5 VDC, 1 A Power Consumption Basic: 1.6 WMax.: 3.8 W (live + IR + PT rotation) Environment Operating Temperature –10 °C to +45 °C (+14 °F to + 113 °F) Operating Humidity ≤95% Structure Casing Material Plastic Product Dimensions φ84 mm × 123.8 mm (φ3.31" × 4.87") Net Weight 206.5 g (0.46 lb)

Read more less

Pre-order: will take 2-3 days for process.    Specifications:  Camera Image Sensor 1/3.2" CMOS Max. Resolution 1920 (H) × 1080 (V) Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Illumination Distance Up to 10 m (32.81 ft) (IR) Illuminator On/Off Control Auto Illuminator Number 1 (IR LED) Angle Adjustment Pan: 0° to 355°.Tilt: -5° to +80° Max. Aperture 3.6 mm: F2.0 Field of View 3.6 mm: H: 79°; V: 43°; D: 94° Video & Audio Video Compression H.265 Video Frame Rate Mainstream: 1920 × 1080 @25 fps Sub stream: 640 × 480 @25 fps Resolution 1080p (1920 × 1080); VGA (640 × 480) Video Bit Rate H.265: 80 kbps–4096 kbps Day/Night Auto (ICR)/Color/B/W WDR DWDR Motion Detection OFF/ON Image Rotation 0°/180° Built-in MIC Yes, built-in Mic Built-in Speaker Yes, built-in speaker Audio Compression G.711a Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; motion detection; audio detection Network Network Port RJ-45 (10/100 Base-T) Wi-Fi IEEE 802.11b/g/n 2.4–2.4835 GHz, 2.4 G Storage Micro SD card (up to 256 GB) Management Software DMSS Mobile Client iOS; Android General Certifications CE Power Supply 5 VDC, 1A Power Consumption Basic: 1.8 W;Max. (video stream acquiring + IR + PTZ Rotation): 3.5 W Operating Temperature –10 °C to +45 °C (+14 °F to +113 °F) Operating Humidity ≤ 95% Casing Material Plastic Product Dimensions φ77.8 mm × 108.1 mm (φ3.06" × 4.26") Net Weight 204.2 g (0.45 lb)

Read more less

Pre-order: will take 2-3 days for process.    Specifications:  Camera Image Sensor 1/3" CMOS Max. Resolution 2560 × 1440 ROM 16 MB RAM 64 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.03 Lux@F2.0 (Color, 30 IRE) 0.003 Lux@F2.0 (B/W, 30 IRE) 0 lux (Illuminator on) S/N Ratio > 56 dB Illumination Distance 30 m (98.43 ft) Illuminator On/Off Control Auto; Manual Illuminator Number 1 (IR LED) Pan/Tilt/Rotation Range Pan: 0°–360°Tilt: 0°–90°Rotation: 0°–360° Lens Lens Type Fixed-focal Lens Mount M12 Focal Length 2.8 mm; 3.6 mm Max. Aperture F2.0 Field of View 2.8 mm:Horizontal: 90°; Vertical: 50°; Diagonal: 107°3.6 mm:Horizontal: 76°; Vertical: 40°; Diagonal: 92° Iris Control Fixed Close Focus Distance 2.8 mm: 1.0 m (3.28 ft)3.6 mm: 1.4 m (4.59 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8mm 68.0 m (223.10 ft) 27.2 m (89.24 ft) 13.6 m (44.62 ft) 6.8 m (22.31 ft) 3.6mm 85.2 m (279.53 ft) 34.1 m (111.88 ft) 17.0 m (55.77 ft) 8.5 m (27.89 ft) Video Video Compression H.264B; H.264; H.264H; H.265 Smart Codec Smart H.265+; Smart H.264+ Video Frame Rate Mainstream:2560 × 1440 (1–20 fps)Sub stream:640 × 480@ (1–25 fps) 640 × 480@ (1–30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Stream Capability 2 streams Resolution 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720) Bit Rate Control CBR/VBR Video Bit Rate H264: 24 kbps–4096 kbps H265: 9 kbps–4096 kbps Day/Night Auto (ICR)/Color/B/W BLC Yes WDR DWDR White Balance Auto; natural; street lamp; outdoor; manual; regional custom Gain Control Auto Noise Reduction 3D NR Motion Detection OFF/ON (4 areas, rectangular) Smart Illumination Yes Image Rotation 0°/180° Mirror Yes Audio Built-in MIC Yes Built-in Speaker Yes Audio Compression G.711a; G.711Mu Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; intensity change Network Network Port RJ-45 (10/100 Base-T) Wi-Fi IEEE802.11b/g/n 2.4–2.4835 GHz; 2.4 G Wireless Range Up to 150 m (The performance varies based on actual environment) SDK and API Yes Cyber Security Video encryption; configuration encryption; Digest;WSSE; account lockout; security logs; generation andimporting of X.509 certification; HTTPS; trusted boot;trusted execution; trusted upgrade Network Protocol IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP Interoperability ONVIF (Profile S/Profile T); CGI; P2P User/Host 6 (Total bandwidth: 36 M) Storage Micro SD card (support max. 256 GB) Browser IEChromeFirefox Management Software Smart PSS; DSS; DMSS Mobile Client iOS; Android Certification Certifications CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU; FCC: 47 CFR FCC Part 15, Subpart B; FCC ID: FCC PART 15C Power Power Supply 12 VDC Power Consumption Basic: 2.1 W (12 VDC) Max. (H.265+IR intensity):6.1 W (12 VDC) Environment Operating Temperature –30 °C to +50 °C (–22 °F to +122 °F) Operating Humidity ≤ 95% Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F) Protection IP67 Structure Casing Front cover: Plastic Rear: Plastic Bracket: Metal Product Dimensions 180 mm × 83.3 mm × 114.8 mm (7.09" × 3.28" × 4.52") Net Weight 350.1 g (0.77 lb) Gross Weight 588.1 g (1.30 lb)

Read more less

Pre-order: will take 2-3 days for process.    Specification: Camera Image Sensor 1/2.8" CMOS Max. Resolution 1920 (H) × 1080 (V) ROM 16 MB RAM 64 MB Scanning System Progressive Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s Min. Illumination 0.025 lux@F2.0 (Color, 30 IRE) 0.0025 lux@F2.0 (B/W, 30 IRE) 0 lux (Illuminator on) S/N Ratio > 56 dB Illumination Distance 30 m (98.43 ft) Illuminator On/Off Control Auto; Manual Illuminator Number 1 (IR LED) Pan/Tilt/Rotation Range Pan: 0°–360°Tilt: 0°–90°Rotation: 0°–360° Lens Lens Type Fixed-focal Lens Mount M12 Focal Length 2.8 mm; 3.6 mm Max. Aperture F2.0 Field of View 2.8 mm:Horizontal: 100°; Vertical: 53°; Diagonal: 120°3.6 mm:Horizontal: 86°; Vertical: 43°; Diagonal: 102° Iris Control Fixed Close Focus Distance 2.8 mm: 0.6 m (1.97 ft)3.6 mm: 1.0 m (3.28 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8mm 46.9 m (153.87 ft) 18.8 m (61.68 ft) 9.4 m (30.84 ft) 4.7 m (15.42 ft) 3.6mm 58.8 m (192.91 ft) 23.5 m (77.10 ft) 11.8 m (38.71 ft) 5.9 m (19.36 ft) Video Video Compression H.264B; H.264; H.264H; H.265 Smart Codec Smart H.265+; Smart H.264+ Video Frame Rate Mainstream:1920 × 1080 (1–25/30 fps)Sub stream: 640 × 480@ (1–25 fps) 640 × 480@ (1–30 fps)*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. Stream Capability 2 streams Resolution 1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720) Bit Rate Control CBR/VBR Video Bit Rate H264: 24 kbps–4096 kbps H265: 9 kbps–4096 kbps Day/Night Auto (ICR)/Color/B/W BLC Yes WDR DWDR White Balance Auto; natural; streetlamp; outdoor; manual; regional custom Gain Control Auto Noise Reduction 3D NR Motion Detection 1024 kbps (1080p) Smart Illumination Yes Image Rotation 0°/180° Mirror Yes Audio Built-in MIC Yes Built-in Speaker Yes Audio Compression G.711a; G.711Mu Alarm Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; intensity change Network Network Port RJ-45 (10/100 Base-T) Wi-Fi IEEE802.11b/g/n 2.4–2.4835 GHz; 2.4 G Wireless Range Up to 150 m (The performance varies based on actual environment) SDK and API Yes Cyber Security Video encryption; configuration encryption; Digest.WSSE; account lockout; security logs; generation andimporting of X.509 certification; HTTPS; trusted boot.trusted execution; trusted upgrade Network Protocol IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP Interoperability ONVIF (Profile S/Profile T); CGI; P2P User/Host 6 (Total bandwidth: 36 M) Storage Micro SD card (support max. 256 GB) Browser IEChromeFirefox Management Software Smart PSS; DSS; DMSS Mobile Client iOS; Android Certification Certifications CE-LVD: EN62368-1. CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU. CE-RED: Radio Equipment Directive 2014/53/EU. FCC:47 CFR FCC Part 15, Subpart B. FCC ID: FCC PART 15C Power Power Supply 12 VDC Power Consumption Basic: 2.2 W (12 VDC) Max. (H.265+IR intensity):6.21 W (12 VDC) Environment Operating Temperature –30 °C to +50 °C (–22 °F to +122 °F) Operating Humidity ≤ 95% Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F) Protection IP67 Structure Casing Front cover: Plastic Rear: Plastic Bracket: Metal Product Dimensions 180 mm × 83.3 mm × 114.8 mm (7.09" × 3.28" × 4.52") Net Weight 350.1 g (0.77 lb) Gross Weight 588.1 g (1.30 lb)

Read more less

Pre-order: will take 2-3 days for process.  Specification Hardware WAN Port 1×10/100/1000 Mbps LAN Port 3×10/100/1000 Mbps Reset Button 1 WPS Button 1 Power Consumption <12 W Memory 128 MB Flash and 256 MB RAM Indicator Light PWR Wireless Standard 2.4 GHz: 802.11 b/g/n/ax 5 GHz: 802.11 a/n/a/ac/ax Performance Operating Frequency 2.412 GHz–2.484 GHz 5.150 GHz–5.850 GHz Wireless Transmission Rate 2.4 GHz: 574 Mbps 5 GHz: 1201 Mbps Channel Width 20/40/80 MHz Max. Output Power 20 dBm ± 2 dBm Antenna Gain 2.4 GHz: 5dBi (±0.5) 5 GHz: 5dBi (±0.5) Receiver Sensitivity 2.4 GHz 11n HT20_MCS0: -95 dbm 11n HT20_MCS7: -75 dbm 11n HT40_MCS0: -92 dbm 11n HT40_MCS7: -72 dbm 11ax HE20_MCS0: -95 dbm 11ax HE20_MCS11: -65 dbm 11ax HE40_MCS0: -92 dbm 11ax HE40_MCS11: -62 dbm 5 GHz 11ac VHT80_MCS0: -89 dbm 11ac VHT80_MCS9:-62 dbm 11ax HE80_MCS0: -89 dbm 11ax HE80_MCS11:-59 dbm Optimal Transmission Distance 63 m (206.69 ft) Channel 2.4 GHz: 1-13 5 GHz: 36/40/44/48,52/56/60/64,149/151/153/157/1 61/165 Connected Wireless Terminals 2.4 GHz: 32 5 GHz: 32 Function Encryption Mode WPA-PSK WPA-PSK/WPA2-PSKWPA2-PSKWPA2-PSK/WPA3- SAEWPA3-SAE Management and Log NTP; Syslog Firmware Update Web/WiLynk App update OFDMA Yes MU-MIMO 2x2 DHCP Yes NAT Mapping based on port VPN L2TP PPTP QoS Yes DDNS Yes Parental Controls Yes Equipment Management Yes General Power Supply 12 VDC,1 A Operating Temperature 0 °C to 40 °C (32 °F to 104 °F) Storage Temperature –20 °C to +70 °C (–4 °F to 158 °F) Operating Humidity 10%–90% (RH), non-condensing Gross Weight 0.73 kg (1.61 lb) Net Weight 0.43 kg (0.95 lb) Packaging Dimensions 309 mm × 298 mm × 61 mm (12.17" × 11.73" × 2.40") (L × W × H) Product Dimensions 252 mm × 155mm × 178 mm (9.92" × 6.10" × 7.01") (L× W × H) Statics Protection Air discharge: 8 kV Contact discharge: 6 kV Lighting Protection Common mode: 2 kV Differential mode: 0.5 kV Installation Desktop mount Packing List 1 × Device 1 × Power adapter 1 × Ethernet cable 1 × Quick Start Guide 1 × Legal and Regulatory Information WARRANTY: 1YEAR

Read more less

Pre-order: will take 2-3 days for process.  Technical Specification Hardware Physical Port 1 × 10/100/1000Mbps WAN 2 × 10/100/1000Mbps LAN Power Consumption: <10 W Memory: 128 MB Flash and 128 MB RAM Indicator Light 1 × WPS 1 × 5GHz, 1 x 2.4GHz 1 × LAN 1 × Internet 1 × PWR Button 1 × Reset/WPS button Wireless Standard 2.4 GHz: 802.11 b/g/n 5 GHz: 802.11 a/n/a/ac/ax Performance Operating Frequency 2.412 GHz–2.484 GHz 5.150 GHz–5.850 GHz Wireless Transmission Rate 2.4 GHz: 300 Mbps 5 GHz: 1201 Mbps Channel Width 20/40/80 MHz Max. Output Power 20 dBm ± 2 dBm Antenna Gain 2.4 GHz: 5dBi (±0.5) 5 GHz: 5dBi (±0.5) Receiver Sensitivity 2.4 GHz 11n HT20_MCS0: -95 dbm 11n HT20_MCS7: -75 dbm 11n HT40_MCS0: -92 dbm 11n HT40_MCS7: -72 dbm 5 GHz 11ac VHT80_MCS0: -89 dbm 11ac VHT80_MCS9: -62 dbm 11ax HE80_MCS0: -89 dbm 11ax HE80_MCS11: -59 dbm Channel 2.4 GHz: 1-13 5 GHz: 36/40/44/48,52/56/60/64,149/151/153/157 /161/165 Connected Wireless Terminals 2.4 GHz: 16 5 GHz: 32 Function Encryption Mode WPA-PSK WPA2-PSK WPA3-AES WPA/WPA2-PSK WPA2-PSK/WPA3-AES Management and Log NTP; Syslog Firmware Update Web/WiLynk App update OFDMA Yes MU-MIMO 2 × 2 DHCP: Yes NAT Mapping based on port QoS: Yes DDNS: Yes WARRANTY: 1YEAR

Read more less
